Complies with EMC anti-electromagnetic interference standards
Support high-performance, wide-temperature and wide-voltage customization
Seamless full-screen panel, IP65 dust and water resistance
Capacitive 10-point touch, fast and accurate response to operation
Energy saving and low consumption, 24-hour uninterrupted and stable operation
| Android AIO computer | |
| Screen size | 7 inches |
| Resolution | 1280*800 |
| Brightness | 320 cd/m2 |
| Colour | 16.7M |
| Ratio | 1000:1 |
| visual Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Display area | 216.96(W)×135.6(H) mm |
| Type | Capactive |
| Communication mode | USB communicate |
| Touch method | Fingure/Capactive pen |
| Touch life | Capactive＞50 Milion |
| luminousness | >87% |
| Surface hardness | ＞7H |
| Glass type | Chemically enhanced plexiglass |
| Mainboard model | RK3568 |
| CPU | RK3568，Cortex-A55 2.0GHz |
| RAM | 2G（4G/8G Optional） |
| ROM | 16G（MAX 128G optional） |
| System | Android 11 |
| 4G MODULE | available |
| WIFI | WIFI-2.4G（optional WIFI-5.0G） |
| BT | BT-4.1 |
| GPS | available |
| MIC | available |
| RTC | Support |
| Wake on LAN | Support |
| Timing switcher | Support |
| System upgrade | USB upgrade |
| MB Power1 | 1*DC12V/5521 |
| MB Power2 | 1*Wide voltage power supply 9~36V CLIPLINE（optional） |
| HDMI | 1*HDMI |
| USB-OTG | 1*USB3.0 |
| USB-HOST | 1*USB2.0 |
| TF Slot | 1*TF |
| RJ45 | 1*1000M |
| SIM Slot | 1*SIM |
| RS232 | 2*RS232 |
| RS485 | 1*RS485（optional） |
| Audio | 1*3.5mm |
| Material | CNC Sand blasting oxidation process of aluminum alloy |
| Colour | Blackc |
| Adapter Input | AC 100-240V 50/60Hz CCC、CE certificate |
| Power input | DC12V / 4A |
| Power consume | ≤12W |
| Backlit life | 50000h |
| Environment temp | Function temp：-10-60℃，Storage temp：-20-70℃ |
| Humidity | ≤95% |
| installation | Embedded/Wallmounted/Foldable stand/Cantilever mounting |
| Warranty | 12 month |
| Maintenance | Post |
| N.W. | |
| G.W. | |
| Dimension | 202.4*137.4*57mm |
| installation frame size | 190*126mm |
| Carton dimension | |
| Power cable | 1*Power cable1.2M |
| Power adapter | 1*Power adapter1.2M |
| QC Certificate | 1*QC certificate |
| Warranty | 1*Warranty |
